China Integral Flanged Globe Valve API 602 Forged Steel Globe Valve

-

API 602 F11 Globe Valve, Integral Flanged ,DN40 ,1500LB, RF

Model:STV-J41Y-1500LB-DN40-F11

The shape of the API 602 F11 Globe Valve opening and closing member and the valve flow passage allows the valve to have a certain flow characteristic. This must be taken into consideration when selecting a valve.

STV Valve Technology Group Co., Ltd is a professional leader China Integral Flanged Globe Valve ,High Pressure Globe Valve ,Forged Carbon Steel Globe Valve,API 602 Globe Valve, API 602 Forged Steel Globe Valve,1500LB Globe Valve,F11 Globe Valve manufacturer with high quality and competitive price.

Please contact our sales@stvvalve.com for other materials and details.

Date Sheet:API 602 F11 Globe Valve, Integral Flanged ,DN40 ,1500LB, RF

Categories: ,  Tags: , , , , , ,

Description

Product Detail

Design Standard:API602.
Body Material: F11
Nominal Diameter: 11/2 Inch (DN40).
Pressure: Class 1500.
End Connection: RF.
Face to Face: ASME B16.10.
Working Temperature: -29℃~+560℃.
Mode of Operation: Handwheel.
Test and Inspection: API 598.

Product Range

Body Material: A105、LF2、F5、F11、F22、304、304L、316、316L、F51、F91、20#、Inconel .Ect
Normal diameter: 1/2″~2″ (DN15~DN80).
End connection: NPT, SW, Butt-Weld, Flanged.
Pressure range: 150lbs~2500lbs(PN10~PN420).
Operation: Hand wheel, Electric,Pneumatic Actuator
Working temperature: -196℃~ +560℃.
Product NameAPI 602 F11 Globe Valve, Integral Flanged ,DN40 ,1500LB, RF
1. MaterialF11
2. Size11/2”
4. PortReducer Port
5. Working Pressure1500lb
6. Connection EndsRF
7. Working Temp.-29~425ºC,
8. Suitable MediumWater, Natural Gas, Oil and some corrosive liquid
9. OperatedHandwheel
10. Inspection & TestingAccording to API598
Shipment
Delivery Time30 Days
PackageStandard Exporting Plywood Case
Shipping PortNingbo/Shanghai, China
Shipping TermsExw, FOB, CFR, CIF, etc.
Payment TermsT/T, Western Union, PayPal, etc.
30% prepayment, 70% balance paid before shipping
Country of OriginWenzhou city, China
Production Capacity6000 ton/year
MOQ1 PCS/size
